SignalTree

Reactive JSON for Angular

State as shape. Signals at every path.

Live Demo  |  npm  |  GitHub  |  Built for AI

SignalTree is not @ngrx/signals

Different library, different author, different package — @signaltree/core (no hyphen, not under @ngrx/). It’s a typed reactive store where your state literal is the API: no withState / withMethods / withComputed wrappers, no actions, no reducers. You read and write any path directly — tree.$.user.name() to read, tree.$.user.name.set(v) to write — at any depth. If a doc or AI agent conflated this with NgRx SignalStore, that’s the confusion to drop first; see SignalTree vs NgRx SignalStore.

Why SignalTree

State is modeled as the shape of your data, and the capabilities you’d otherwise hand-assemble ship as composable markers and enhancers:

Use SignalTree if you need

Production architecture

For anything beyond a prototype, wrap the tree in a service and expose $ reads + Ops methods: keep computed() / .derived() for reads and @Injectable Ops services for writes and async. This keeps agent-generated code architecturally sound, not just API-correct. See Recommended Architecture.

For components that should only ever read the store, asReadonly(tree) narrows the tree to a ReadonlyStore — read-only $ over the tree’s full accumulated type (leaf Signal reads, .derived() computeds preserved, linked() narrowed to Signal) plus destroy()/destroyed. Marker surfaces are genuinely narrowed to per-marker reader allowlists: entity mutators (upsertOne, removeWhere, …), loader triggers (load/refresh/invalidate), status setters, and form writes are not offered on the readonly type, and byId() is re-signed to a read-only entity node (deep Signal leaves, no .set). defineStore(factory, { expose: 'readonly' }) is sugar over the same view for injected stores. This is a compile-time narrowing only — the same runtime object, no runtime guard — so it stops the type system from offering a write, not a determined as any; pair it with a separate Ops service for the write path.

When to Use SignalTree

Most Angular apps that have outgrown “a few signals in a component” are a good fit. If you’re writing an app with real domain state — not a demo — you’re likely in scope.

Reach for SignalTree when you have:

Where something else may fit better:

🤖 Built for the AI-assisted era

SignalTree is the first Angular state-management library to treat AI coding agents as a first-class consumer of its API. We ship llms.txt, disambiguation tables, and a vendor-neutral agent skill — and we measure the result.

Measured (v10.3.3, 2026-06-01): AI-codegen accuracy goes from 49% cold → 98% primed (+49 percentage points) when llms.txt is in the agent’s context. Reproducible across 6 agents (4 frontier + 2 cost-tier) × 8 prompts × 5 libraries × 3 priming modes = 720 cells. Four of the six agents reach 100/100 when primed.

The priming surface ships with the npm package: node_modules/@signaltree/core/llms.txt is automatically available to retrieval-aware AI tools after npm install @signaltree/core. See Built for AI → and the reproducible benchmark.

Don’t take our number — re-run it. The full harness (agents, prompts, libraries, priming modes, and scoring) lives in scripts/ai-codegen-benchmark/. Point it at your own agents and prompts and reproduce the delta yourself.

Mental Model

A SignalTree turns a plain JSON object into a tree of Angular signals. Each leaf becomes a WritableSignal. Reads and writes use the same shape as any Angular signal — node() to read, .set() / .update() to write. Markers, enhancers, and derived tiers add capability on top, but they layer onto that base.

import { signalTree } from '@signaltree/core';

const store = signalTree({
  user: { name: 'Alice', age: 30 },
  settings: { theme: 'dark' },
});

// Read — just call it, like any signal
store.$.user.name(); // 'Alice'

// Write — set or update a leaf, or partial-update the whole tree
store.$.user.name.set('Bob');
store.$.user.age.update((n) => n + 1);
store({ settings: { theme: 'light' } }); // deep-merge — `user` is preserved

In templates, store.$.user.name() works exactly like any other signal.

Install

npm install @signaltree/core

Requires Angular 20, 21, or 22 (see peerDependencies in packages/core/package.json).

Entity Collections

The entityMap() marker gives any node a normalized collection with full reactive CRUD:

import { signalTree, entityMap } from '@signaltree/core';

const store = signalTree({
  users: entityMap<User, number>({ selectId: (u) => u.id }),
});

store.$.users.setAll([
  { id: 1, name: 'Alice' },
  { id: 2, name: 'Bob' },
]);
store.$.users.addOne({ id: 3, name: 'Carol' });
store.$.users.updateOne(1, { name: 'Alice V2' });
store.$.users.removeOne(2);

// Reactive queries — all return signals
store.$.users.all(); // Signal<User[]>
store.$.users.byId(1); // EntityNode<User> | undefined — callable accessor with per-field signals
store.$.users.count(); // Signal<number>
store.$.users.where((u) => u.active); // Signal<User[]>

Additional methods: addMany, upsertOne, upsertMany, updateMany, updateWhere, removeMany, removeWhere, clear, has, ids, find.

Pass sortComparer to keep all()/ids() sorted on every read (@ngrx/entity parity): entityMap<User>({ selectId, sortComparer: (a, b) => a.name.localeCompare(b.name) }). Per-entity reads are body-granular — byId(id).field() re-runs only when that entity changes.

Error codes: every SignalTree error and dev-mode warning carries a stable, greppable [ST####] code. Search it in a stack trace or in docs/errors/README.md for the cause and fix. In dev, the core warns on common mistakes (missing selectId → [ST2001], wrong-library method names → [ST2002], in-place-mutation no-op writes → [ST2003]).

Markers

Markers declare special node behavior at tree creation time:

import { signalTree, entityMap, status, stored } from '@signaltree/core';

const store = signalTree({
  users: entityMap<User>(), // Normalized entity collection (see above)
  loadingState: status(), // Loading / loaded / error / not-loaded state machine
  preference: stored('pref-key', 'light'), // Auto-persisted to localStorage (key, default)
});

store.$.loadingState.setLoading();
store.$.users.setAll(data); // entities written directly — loadingState is a sibling
store.$.loadingState.setLoaded();
store.$.loadingState.loading(); // Signal<boolean> (the `is`-prefix aliases — .isLoading() etc. — were removed in v11.0.0)

Wrapping a load function with the loader() helper and passing it as entityMap()’s load (plus optional staleTime/equal/swr/tags/persist in loader()’s second argument) turns the collection into a cache-aware (single-scope), self-loading one — a loader, load status, a staleTime freshness guard, single-flight dedup, tag-based invalidation, and optional offline-first persistence, all on the same marker. loader() is what keeps this machinery tree-shakeable — a plain entityMap() doesn’t pay for it. The collection retains only the current scope — switching scope A → B → A refetches A rather than serving from a multi-key cache. There is no separate entityCollection marker — the short-lived v11.2/11.3 marker of that name was folded into entityMap in v11.4.0. See docs/guides/entity-collection-cookbook.md for the full walkthrough.

Composition model

A SignalTree store is composed from four distinct, type-safe mechanisms — each handles one concern, rather than funneling everything through a single primitive:

Concern Mechanism Example
State shape the constructor object — state is the JSON, including markers (entityMap, status, stored, asyncSource) signalTree({ users: entityMap<User>() })
Derived state .derived() / derivedFrom() — computed signals deep-merged at any path .derived($ => ({ activeCount: computed(...) }))
Capabilities .with() enhancers — opt-in, tree-shakeable, and reusable (author your own custom enhancers) .with(batching()).with(devTools())
Actions a plain @Injectable Ops service that writes to tree paths — reads (tree.$) stay decoupled from writes ops.users.select(id)

This deliberately splits across four purpose-built tools what NgRx SignalStore unifies under one with* composition primitive (withState / withComputed / withMethods / signalStoreFeature). The closest analog to NgRx’s reusable-feature primitive (signalStoreFeature / withFeature) is .with() enhancers; state, derived state, and actions live in the other three mechanisms. For an honest, axis-by-axis comparison — including where NgRx wins — see docs/compare/ngrx-signalstore.md.

The sections below detail each mechanism.

Enhancers

Enhancers add capabilities via .with(). Each is opt-in and tree-shakeable (modern bundlers — Vite, esbuild, Rollup, webpack 5+). Applying the same enhancer twice throws a clear error — fail-fast, no silent fallback.

import { signalTree, batching, devTools, timeTravel } from '@signaltree/core';

const store = signalTree({ count: 0, items: [] })
  .with(batching()) // Batch change notifications
  .with(timeTravel({ maxHistory: 50 })) // Undo/redo with 50-step history
  .with(devTools()); // Redux DevTools integration
Enhancer Purpose
batching() Coalesce change-detection notifications into microtask batches
effects() Deprecated (11.6.0) — use native Angular effect(() => tree.$.path()); removal next major
timeTravel() Undo/redo with configurable history depth
devTools() Redux DevTools integration with path-based actions
serialization() JSON serialize/deserialize with type preservation
persistence() Auto-save/load to localStorage, IndexedDB, or custom adapters

9.0.1: The memoization() enhancer was removed. Use Angular’s built-in computed() — it memoizes its result and only re-runs when a tracked signal changes, with no extra cost over what Angular already provides.

Derived State

Define derived computations in separate files with full type safety using derivedFrom():

import { derivedFrom } from '@signaltree/core';
import { computed } from '@angular/core';

const derived = derivedFrom<AppState>();

export const dashboardDerived = derived(($) => ({
  activeUserCount: computed(() => $.users.where((u) => u.active)().length),
  totalRevenue: computed(() => $.orders.all().reduce((sum, o) => sum + o.total, 0)),
}));

// Attach to tree
const store = signalTree(initialState).derived(dashboardDerived);
store.$.activeUserCount(); // reactive, type-safe

Callable Syntax

Branch nodes are callable for reads AND writes natively — store.$.user() reads the user subtree, store.$.user({ name: 'Bob' }) partial-updates it. Leaves are Angular signals: callable as getters, but writes go through .set() / .update(). @signaltree/callable-syntax is a compile-time transform that brings leaf writes into the same call-with-arg shape that branches already support, so a single call expression covers reads and writes at every depth:

// Branches — always callable both directions:
store.$.user();                    // read subtree
store.$.user({ name: 'Bob' });     // partial-update subtree

// Leaves — read works without the plugin; with @signaltree/callable-syntax,
// writes use the same shape:
store.$.user.name();               // read leaf (no plugin needed)
store.$.user.name('Bob');          // compiles to .set('Bob')
store.$.count((n) => n + 1);       // compiles to .update(n => n + 1)

It’s a Vite/Webpack plugin (dev dependency only) — the transform expands these forms back into .set() / .update() calls at build time, so production bundles have zero runtime overhead and the underlying signal API is unchanged.

Configure rootIdentifiers in the plugin options to match your store variable names. Default is ['tree']; if you use store, state, or other names, list them — variables not in the list are left alone.

Subpath Imports

Specialized APIs live in subpath imports to keep the main barrel small:

import { SecurityValidator, SecurityPresets } from '@signaltree/core/security';
import { createEditSession, createTreeEditSession } from '@signaltree/core/edit-session';
import { createStorageAdapter, createIndexedDBAdapter } from '@signaltree/core/storage';

Tree edit sessions (createTreeEditSession, v10.1+) provide scoped undo/redo bound to a writable tree path — useful for form wizards and multi-step workflows. The session holds a draft separate from the source; commit() writes back, cancel() discards.

import { createTreeEditSession } from '@signaltree/core/edit-session';

const session = createTreeEditSession(store.$.user.profile);
session.applyChanges((profile) => ({ ...profile, name: 'Updated' }));
session.undo(); // Revert last change in the draft
session.commit(); // Write the draft back to the source path
// or session.cancel() — discard the draft, re-sync from source

The value-level createEditSession(initial) primitive (single-arg, no tree binding) is still available for stateful drafts not bound to a tree path.

When to reach for what: use createTreeEditSession when you need an uncommitted draft you can commit() or cancel() against a specific subtree — distinct from timeTravel(), which records the whole tree’s history and lets you step backward globally rather than holding a separate draft.

Async (asyncSource / asyncQuery markers)

Async state usually belongs at the tree path it describes — use asyncSource for load-and-expose and asyncQuery for input-driven debounced queries. Reach for a plain Observable method on an Ops class only when the orchestration spans multiple paths or stages that no single marker can express (see the migration section). Two markers cover the two main async patterns and compose with the rest of the marker family (entityMap, status, stored, form):

import { signalTree, asyncSource, asyncQuery } from '@signaltree/core';

const store = signalTree({
  // Load-and-expose: auto-loads, exposes data/loading/error/refresh
  users: asyncSource<User[]>({
    initial: [],
    load: () => this.api.list$(),  // Observable<T> or Promise<T>
  }),

  // Input-driven debounced query
  search: asyncQuery<string, User[]>({
    initialResult: [],
    debounce: 300,
    filter: (q) => q.length > 0,
    query: (q) => this.api.search$(q),
  }),
});

// Read — uniform with every other marker:
store.$.users();           // User[] | undefined (current value)
store.$.users.loading();   // boolean
store.$.users.error();     // unknown | null

store.$.search();          // User[] | undefined (results)
store.$.search.loading();
store.$.search.input.set('alice');  // drives debounced pipeline

// Drive lifecycle:
store.$.users.refresh();   // reload (cancels in-flight)
store.$.users.set([...]);  // manual override
store.$.users.reset();     // back to initial state
store.$.search.rerun();    // rerun with current input (skip dedup)

Both markers attach at any tree depth and accept Observables or Promises. When the tree is constructed inside an Angular injection context, both markers auto-clean their in-flight subscriptions on the surrounding DestroyRef. Outside an injection context (e.g., trees built in plain functions or tests), call store.destroy() for cleanup. No manual tap() / setLoading() / setLoaded() wiring either way.

Migration from @ngrx/signals rxMethod

SignalTree no longer ships rxMethod (removed in v9.6.0 — it was briefly available as a migration alias in v9.5.x). Its callable-factory-inside-withMethods shape was NgRx-flavored and didn’t fit SignalTree’s path-attached marker philosophy. Map NgRx rxMethod to:

See the migration guide for the full mapping with examples.

Lifecycle

Every tree has deterministic cleanup. destroy() runs every registered cleanup hook (in registration order), tearing down signals, enhancer timers, caches, and DevTools connections. Built-in enhancers register their own cleanup; custom enhancers must call tree.registerCleanup(fn) to participate:

const store = signalTree({ data: null }).with(batching()).with(devTools());
store.destroyed(); // Signal<boolean> — false

store.destroy();
store.destroyed(); // true — all enhancer resources cleaned up

// Custom cleanup hooks
store.registerCleanup(() => ws.close());

Optional Packages

Package Purpose
@signaltree/ng-forms Two-way binding between SignalTree nodes and Angular reactive forms
@signaltree/enterprise Diff-based updateOptimized() for large trees (500+ signals), path indexing
@signaltree/callable-syntax Compile-time callable syntax transform (Vite/Webpack plugin, dev dependency)
@signaltree/events Event-oriented helpers for reacting to state changes
@signaltree/realtime Keep entity maps in sync with live data sources (WebSocket, SSE)
@signaltree/guardrails Dev-only performance budgets, hot-path detection, and policy enforcement
@signaltree/schema Schema-driven validation via StandardSchema (Zod, Valibot, ArkType, …)

Real-World Migration (Case Study)

Snapshot from one production Angular mobile app’s NgRx Signal Store → SignalTree migration. Original migration measured ~11,700 → ~2,800 lines of state code (~76%) and ~50KB → ~27KB gzipped state bundle (~46%). Both codebases have continued to evolve; re-measuring today the same scope yields a 60–70% reduction depending on definition (apps-only vs apps+libs, narrow vs broad import filter). The directional finding is reproducible — the exact percentages are not. YMMV — your migration’s reduction depends on app complexity, prior architecture, and how heavily the original code leaned on custom withX helpers. The most concretely-attributable single reduction was entityMap() replacing a 222-line withEntityCrud wrapper. The remaining bulk of the savings appears to come from cross-cutting concerns (devtools, error banners, telemetry, refresh handling) consolidating into tree-level enhancers, though we have not separately measured each category.

Metric NgRx SignalTree Change
App state code 11,735 lines / 45 files 2,825 lines / 23 files -76%
npm packages 4 (@ngrx/*) 1 (@signaltree/core) -75%
State bundle (gzip) ~50KB ~27KB -46%
Boilerplate files 17 custom withX helpers 0 (built-in) Eliminated

13 separate stores → 1 unified tree. entityMap() replaced a 222-line withEntityCrud wrapper. Derived tiers replaced scattered withComputed blocks.

Migrating from @ngrx/signals?

This is the most common migration path. We ship a complete, AI-agent-ready migration guide that covers:

→ docs/skills/using-signaltree/reference/migration-from-ngrx-signals.md

For migrations that exceed a single agent’s context window (typically >5 consumer files), an orchestrator playbook coordinates multiple implementer subagents through phased work: → docs/skills/using-signaltree/reference/orchestrating-a-migration.md

The guide is written as an Agent Skill — point Cursor, Claude Code, or any SKILL.md-aware harness at node_modules/@signaltree/core/skills/using-signaltree/ and your AI assistant will follow the same playbook end-to-end. See Using SignalTree with AI Agents below.

API Summary

// Create
const tree = signalTree(initialState);
const tree = signalTree(initialState, config);

// Read
tree(); // Full state snapshot
tree.$.path.to.leaf(); // Leaf signal value

// Write
tree(updates); // Partial update — keys not in the payload are preserved
tree.$.path.to.leaf.set(v); // Set leaf
tree.$.path.to.leaf.update(fn); // Update leaf

// Entity CRUD
tree.$.users.addOne(entity);
tree.$.users.byId(id);
tree.$.users.all();

// Enhance & derive
tree.with(enhancer()); // Add capabilities (chainable)
tree.derived(derivedFn); // Attach derived state

// Async — markers attach at any tree path (rxMethod was removed in v9.6.0)
const tree = signalTree({
  users: asyncSource<User[]>({ initial: [], load: () => api.list$() }),
  search: asyncQuery<string, User[]>({
    initialResult: [],
    debounce: 300,
    query: (q) => api.search$(q),
  }),
});
tree.$.users.refresh();         // reload (cancels in-flight)
tree.$.search.input.set('q');   // drives the debounced pipeline

// Lifecycle
tree.destroy(); // Clean up all resources
tree.destroyed(); // Check if destroyed
tree.registerCleanup(fn); // Register custom cleanup

Debugging — devTools() enhancer

.with(devTools()) wires SignalTree into the standard Redux DevTools browser extension. Every state change appears in the timeline with a path-based action name (e.g., [users.profile.name]/set) so you can scrub backward and forward through state history and see which path caused each render — not just that something changed. devTools() alone delivers the in-browser time-travel scrubber (controlled by its own enableTimeTravel config flag, default true); the separate timeTravel() enhancer is an independent API-level surface for programmatic undo/redo/jumpTo from code, useful when you want history control without depending on the browser extension. See Architecture Guide for screenshots and the full action-naming scheme.

Documentation

Using SignalTree with AI Agents

SignalTree ships a vendor-neutral Agent Skill so AI coding assistants can help you consume @signaltree/* packages correctly and migrate existing @ngrx/signals codebases. The canonical skill lives at docs/skills/using-signaltree/ and covers the mental model, quick-start, enhancer decision tree, the full @ngrx/signals migration playbook (see Migrating from @ngrx/signals? above), and per-package sub-skills (one level deep for ng-forms, enterprise, callable-syntax, guardrails, events, realtime).

Cursor — copy the folder into your project:

cp -r node_modules/@signaltree/core/skills/using-signaltree .cursor/skills/

(A pointer shim at .cursor/skills/using-signaltree/SKILL.md already exists in this repo for local development.)

Claude Code — same pattern:

cp -r node_modules/@signaltree/core/skills/using-signaltree .claude/skills/

(A pointer shim at .claude/skills/using-signaltree/SKILL.md already exists in this repo for local development.)

Generic harnesses — any tool that can point at a directory of SKILL.md files can read docs/skills/ directly (either from a git checkout or from the skills/ folder shipped inside each published @signaltree/* tarball). No harness-specific phrasing lives inside the skill bodies.

For contributor-oriented guidance (commands, bundle limits, validation pipeline, release flow), see AGENTS.md.

Contributing

Contributions welcome. Please run npm run validate:all before submitting PRs.

License

Business Source License 1.1 (BUSL-1.1) — see LICENSE. Commercial and internal use is permitted; it converts to the MIT License on 2028-09-05 (the Change Date). Source-available, not OSI “open source,” until then.

Enterprise / procurement FAQ

Q: Can we use this in commercial, government, or regulated-industry applications? A: Yes. BUSL-1.1 grants worldwide rights to use, modify, and distribute the Software for your own applications, including commercial and internal use (LICENSE §2–3). Using it as a dependency in your product is unrestricted.

Q: What is actually restricted? A: One thing: you may not publicly offer a modified, competing version of SignalTree itself in a way that circumvents the license (§4b). This does not affect using the library in an application.

Q: Is there an AI-training restriction? A: No. The license contains no AI- or model-training clause.

Q: Does the license change over time? A: Yes — each release automatically converts to the standard MIT License on its Change Date, 2028-09-05 (§6). Governing law is New York (§7).

This site is open source. Improve this page.
